Thermoplastic reflective road marking paint
Product Introduction
Thermoplastic reflective road marking paint is a new type of pavement marking paint developed on the basis of the original hot-melt road marking paint by appropriate improvement of coating formulation and construction technology. It is mainly composed of C5 petroleum resin, and various additives, pigments, hot-melt special glass beads, etc. are added to form a powdery solid coating, which is heated from 180°C to 220°C by a hot melt kettle.
Specification
◆ Specification
◆ Long service life
◆ Excellent wear resistance
◆ Night reflection
◆ Night reflection
Guide Using
◆ Consumption (Actual consumption depends on the roughness of pavement)
|
Reference Table of Material consumption |
|
|
|
Screed |
|
Thickness |
2mm |
|
Paint |
About 4.5kg/㎡ |
|
Primer |
150g/㎡ |
|
Glass Beads |
350g/㎡ |
◆ Typical installation areas:
·Big and medium city road
·Airport
·Wharf
·Zebra
·Crossing
·Road lane boundary
·Lane edge line
·Bridge,tunnel
·Village,factory road
·Underground garage and underground parking space line
Technical Data:
◆ Curing time:≤3minutes
◆ Compression strength:≥12(23℃)
◆ Retroreflection value ≥150mcd.m-2.lx-1 (white); ≥100mcd.m-2.lx-1 (yellow)
◆ Anti slide swing valve:≥45BPN
◆ Color:White/Yellow/Customize color
